ARC Dijital RADIUS Mastar ve İlgili Modeller

ARC DIGITAL RADIUS Mastar ve İlgili Modeller, Boyutsal karşılaştırma, salgı, derinlik, iç çap ve hassas konum kontrolü için SCHWYZ ürün ailesidir. Modeller, ölçüm aralıkları, çözünürlükler ve teslimat seçenekleri aşağıdaki katalog teknik bilgilerinde yer alır.

Katalog teknik bilgileri:
Choose the measuring jaw: Choose the suitable jaw according to the size of the object. In general, choose a large jaw with a large radius. The jaws are numbered from 10 to 20, 30, 60, and 100 Press the C key to change the C value (that is, the jaw size), and C= 10, 20, 30, 60, 100 will be displayed on the screen in order to make the jaw number correspond to the C value. D10 ARC DIGITAL RADIUS GAUGE • The gauge can measure both inside and outside radius of arc or uncompleted circle automatically • Display the tilt function • Direct display the radius. No need to calculate • With 5 different measuriing jaw • With fitted plastic box • With English manual and instruction • The Gauge can be used as Digital indicator with 0.005mm resolution • Wide Range • With data Hold function • mm/inch convertible • Measure radius of internal and external arcs • Supplied with 5 jaws for different sizes of arc • Battery CR2032 FEATURES: 0.005/0.00005" Unit: mm P5061A 5-700mm/0.2-27.5" ±0.01R Resolution Accuracy mm R=14--> 30MM R=11--> 30MM Unit: mm Outside diameter R=5 --> 13MM R=6.5 --> 15MM R=94-->260MM R=94-->260MM Range of Radius R Best measurement range C=10 C=20 C=30 C=60 C=100 R=255-->700MM R=255-->700MM R=22-->100MM R=27-->100MM Inside diameter Application as indicators • Outside measurement • Inside measurement • Depth measurement • Step measurement BIG-ARC DIGITAL RADIUS GAUGE • Measurement range: From 55 to 11250mm or from 2" to 443" Inches • Power supply: 3V CR2032 Lithium battery (included) • Working temperature: 0±40ºC • Storage and transport temperature: -20ºC – 60ºC • Relative humidity: =80% FEATURES: 0.005/0.00005" Unit: mm P5061B 450-2250mm

Ürün grubu	Komparatörler ve Ölçüm Saatleri
Katalog modelleri	ARC DIGITAL RADIUS GAUGE; Application as indicators; Choose the measuring jaw:; Choose the suitable jaw according to the size of the object.; the screen in order to make the jaw number correspond to the C value.; BIG-ARC DIGITAL RADIUS GAUGE
Katalog	SCHWYZ KOMPORATÖR VE ÇEŞİTLERİ 2025-27
Katalog sayfası	11
