Otomatik Aşındırıcı Kesme Cihazı PENTA 110

AUTOMATIC Aşındırıcı Kesme Cihazı PENTA 110, Metalografik numune kesme, kalıplama, zımparalama, parlatma ve inceleme işlemleri için SCHWYZ ürün ailesidir. Modeller, ölçüm aralıkları, çözünürlükler ve teslimat seçenekleri aşağıdaki katalog teknik bilgilerinde yer alır.

Katalog teknik bilgileri:
AUTOMATIC ABRASIVE CUTTER PENTA 110 • PETA-110 series various cutting modes can satisfy different cutting requirements from the customers. • PETA-110 can be loaded with the cutting discs maximum diameter 300mm and equipped with XYZ three-axis rockerand 7-inch touch screen. It can achieve table- feed cutting (Y axis), chop cutting (Z axis), and segment cutting (YZ axis). The flexible cutting method avoids the damage of the sample in cutting process. PETA-110 offers the following 3 optional models: • PETA-110 Pro Automatic Cutting Machine: LCD Touch Screen, Three-Axis Rocker Control, X-Axis, Y-Axis, Z-Axisautomatic cutting system. Adjustable speed of cutting disc: 1000-3500rpm, the maximum cutting diameter 110 mm. The maximum cutting section: 80x200mm. Laser Positioning. Various cutting modes can realize automatic adjustment of cutting speed in Y and Z directions, pulse cutting and step cutting. • PETA-110 MY manual/automatic integrated semi-automatic cutting machine: LCD Touch Screen. Single-axis Y-Axis rocker, only Y Axis can realize automatic feed and pulse cutting. Z-Axis manual hand-wheel control can realize Z-Axis manual cutting. Cutting disc speed is not adjustable: 2800rpm. • PETA-110M manual cutting machine: No LCD touch screen, operate by control panel and button. Y-axis movement controlled by hand-wheel, it can realize Y-Axis manual feed cutting. Z-axis cutting disc is also controlled by manual. Cutting disc speed is not adjustable: 2800rpm. • PETA-110 is equipped with a caster-movable circulating cooling water tank. Capacity 80L. There are 2 optional filtering type: 1.100μm filter basket (standard) 2.Magnetic filter (optional); • PETA-110 offers the following fixtures: 1.Quick fixture for both right and left side (standard matching); 2.Vertical fixture; 3.Vertical fixture with chain; 4.Customized fixture; Model No. PETA-110 Pro PETA-110AY PETA-110MY PETA-110M Max. Wheel Diameter Φ300mm Φ300mm Φ300mm Φ300mm Min. Wheel Diameter Φ200mm Φ200mm Φ200mm Φ200mm Max. Cutting capacity. Φ Φ110mm Φ110mm Φ110mm Φ110mm Max. Capacity. Cutting HxD 80x200mm 80x200 80x200 80x200 Z-Axis Travel mm 150 150 150 150 Y-Axis Travel mm 200 200 200 200 X-Axis Travel mm 80 - - - T-table Dimensions，mm 280x536 （636） 280x636 280x636 280x636 T-Slot Dimension mm 12 12 12 12 Cutting motor power Kw 4 4 4 4 RPM Wheel Speed 800-3500 800-3500 2800 2800 Control Panel 7 inch Touch Screen 7 inch Touch Screen Buttons Cutting method Smart Cutting Auto Auto Auto Manual Chop Cutting， Z- Axis Auto Auto Manual Manual Table Feed Cutting， Y- Axis Auto Auto Auto Manual Pulse Cutting Y-Axis Z-Axis Y-Axis Y-Axis - Segment Cutting Yes Z-YesA - - Cutting Feed rate，mm/s 0.01-5.0 0.01-5.0 0.01-5.0 - Laser Alignment Yes Option Option Option Weight，Kg 370 370 370 370 Recirculation coolant 80 80 80 80 FEATURES 7 inch Touch Screen J6

Ürün grubu	Metalografi Cihazları ve Sarf Malzemeleri
Katalog modelleri	AUTOMATIC ABRASIVE CUTTER PENTA 110
Katalog	SCHWYZ KESİCİ VE ÖĞÜTÜCÜ CİHAZ VE SARF MALZEMELERİ 2025-27
Katalog sayfası	7
