Zoom Stereo Microscope Sm-900

Zoom Stereo Microscope Sm-900, Profil projeksiyonu, görüntülü ölçüm ve koordinat ölçüm uygulamaları için SCHWYZ ürün ailesidir. Modeller, ölçüm aralıkları, çözünürlükler ve teslimat seçenekleri aşağıdaki katalog teknik bilgilerinde yer alır.

Katalog teknik bilgileri:
N12 ZOOM STEREO MICROSCOPE SM-900 • Sharp stereo erect image over a wide field of view. • 45º inclined and 360º rotational binocular head with locked-in eyepiece.The left ocular-tube with diopter adjustment ±5dp，The interpupillary distance is between 55-75mm • Products CE approved • Power supply 110V/60Hz or 220V/50Hz • Illumination: L1. Incident reflected halogen lamp 12V/10W; Transmitted halogen lamp 12V/10W L2. Incident reflected halogen lamp 12V/10W; Transmitted halogen lamp 12V/10W. Brightness isadjustable. L3. Halogen lamp 12V/10WW for incident lamp and fluorescent lamp 5W for transmitted lamp L4. Halogen lamp 12V/10WW for incident lamp and fluorescent lamp 5W for transmitted lamp Brightness is adjustable L5. Both incident and transmitted light with LED。 • Each set packed in styrofoam and in an inner box. Two sets in one carton, The outer measurement is 41X35X41.50cm (SM-900), 50X37X48cm (SM-910,SM-920). Model No. Standard eyepiece Objective Viewing head Up & Down Mechanism Base /Working stage SM-900 SWF10X ZOOM1X-4X Binocular Pillar style Φ95mm Frosted glass SM-910 SWF10X ZOOM1X-4X Binocular Arm curved style Φ95mm Frosted glass SM-920 SWF10X ZOOM1X-4X Trinocular Pillar style Φ95mm Frosted glass SM-930 SWF10X ZOOM1X-4X Trinocular Arm curved style Φ95mm White/Black Working stage SM-940 SWF10X ZOOM1X-4X Binocular Pillar style Φ95mm Frosted glass SM-950 SWF10X ZOOM1X-4X Binocular Pillar style Φ95mm Frosted glass SM-960 SWF10X ZOOM0.75X-3.6X Binocular Pillar style Φ95mm Frosted glass SM-970 SWF10X ZOOM0.75X-3.6X Binocular Arm curved style Φ95mm Frosted glass SM-980 SWF10X ZOOM0.75X-3.6X Binocular Pillar style Φ95mm Frosted glass Optional accessories: 0.5X、7.5X、1.5X、2X(Auxiliary Objective);WF5X、SWF10X、WF15X、WF20X(Eyepiece); Ring light；White/Black working stage. Model No. Eyepiece Standard Objective Auxiliary Objective 0.5X 0.5X 0.5X 0.5X Objective Field of View Working Distance Field of View Working Distance Field of View Working Distance Field of View Working Distance Field of View Working Distance SM-900~950 WF5X 1-4X 20-5 91 40-11 170 25-6.5 100 13-3.5 42 10-2.5 28 SWF10X 1-4X 23-5.5 91 52-12 170 30-7 100 15-4.8 42 11.5-3 28 WF15X 1-4X 15.5-4 91 36-8.5 170 21-5 100 10.5-2.5 42 8-2 28 WF20X 1-4X 10.5-3 91 25-5.8 170 14-3.5 100 7-1.8 42 5.5-1.5 28 SM-960~980 WF5X 0.75-3.6X 26-6 86 60-13 178 32-7 96 16-4 42.5 12.5-3 25.5 SWF10X 0.75-3.6X 28-6 86 63-14 178 35-8 96 18-4 42.5 14-3 25.5 WF15X 0.75-3.6X 19-4.5 86 43-9.5 178 24-5.5 96 12-3 42.5 9.5-2 25.5 WF20X 0.75-3.6X 12.5-3 86 28-6 178 16-3.5 96 8-2 42.5 6-1.5 25.25 SM-910 SM-970 SM-950 SM-920 FEATURES

Ürün grubu	Optik ve Dokunmalı Ölçüm Sistemleri
Katalog modelleri	ZOOM STEREO MICROSCOPE SM-900
Katalog	SCHWYZ PROJEKSİYON VE DOKUNMA ÖLÇÜMCİHAZLARI 2025-27
Katalog sayfası	13
