XJP-17AT/17BT Metalurji Mikroskobu ve İlgili Modeller

XJP-17AT/17BT Metalurji Mikroskobu ve İlgili Modeller, Metalografik numune kesme, kalıplama, zımparalama, parlatma ve inceleme işlemleri için SCHWYZ ürün ailesidir. Modeller, ölçüm aralıkları, çözünürlükler ve teslimat seçenekleri aşağıdaki katalog teknik bilgilerinde yer alır.

Katalog teknik bilgileri:
J15 XJP-17AT/17BT METALLURGICAL MICROSCOPE • With plan achromatic objectives with long working distance (no cover glass) and wide-field eyepieces, can get clear pictures and wide view field. • Coaxial coarse/fine focus system, with tension adjustable and up stop, minimum division of fine focusing: 2μm. • 6V 20W halogen lamp, brightness control. • Trinocular is compensation, can switch to observe normally or to observe the Polarize, can send 100% of light to top photography port. • Binocular，single diopter adjustment,inclined 30° , comfortable & good- looking.Trinocular can be connected to the camera. 10X wide field plan eyepiece, field Ø18mm，can provide an expanse and smooth space for observation. • The circular chromeplate substage is located in the center of mechanical stage so that enable rotate the specimen in the polarization observation. Observation System Mechanical Stage • Integrated illumination can make upthe difference of halogens by adjusting the spacial position. The illumination mode is“ Kohler illumination” .and the adjustment of field and aperture diaphragm is achieved by turning the control plate,by adding the flashboard ploarizer can be rotated from 0°~90° . the adjustment mode is smooth and comfort. Illumination System • By adding the appurtenance such as CCD adapter, digital camera adapter and single- reverse digital camera adapter and etc. It can achieve high clear observation mode of camera and vidicon Photography Unit Bright type observe Polarized observe Bright type observe Digital camera photography: XJP-17 metallurgical microscopes are used for identification and analysis of the structures in different metals and alloys. They are the important instruments for researching metallography in metal physics. The instruments can select special photography device to take euploid pictures of atlas metallograph. The instruments are suitable for scientific research,colleges and factory. FEATURES

Ürün grubu	Metalografi Cihazları ve Sarf Malzemeleri
Katalog modelleri	XJP-17AT/17BT METALLURGICAL MICROSCOPE; Observation System; Mechanical Stage; Ill umination System; Photography Unit; Digital camera photography:
Katalog	SCHWYZ KESİCİ VE ÖĞÜTÜCÜ CİHAZ VE SARF MALZEMELERİ 2025-27
Katalog sayfası	16
